Siemens OP27 Mono 6AV3627-1JK00-0AX0

vorige | volgende

Te koop:

Technical data

		OPERATOR PANEL OP27 STN MONOCHROME LC DISPLAY
Display
Design of display		STN, 8 gray scales
Screen diagonal		5.7 in
graphics-enabled		Yes
Resolution (pixels)
● Horizontal image resolution		240 Pixel
● Vertical image resolution		320 Pixel
Backlighting
● MTBF backlighting (at 25 °C)		50 000 h
Control elements
Control elements		Keys
Keyboard fonts
● Membrane keyboard		Yes
— user-definable label membrane keys		Yes
● Function keys
— Number of function keys		24
— Number of function keys with LEDs		18
● System keys
— Number of system keys		24
● Numeric keyboard		Yes
● alphanumeric keyboard		Yes
● hexadecimal keyboard		Yes
● Multi-key operation		No
Touch operation
● Design as touch screen		No
Connection type
● Type of connection for mouse/keyboard/barcode reader		- / - / -
Installation type/mounting
Mounting position		vertical
maximum permissible angle of inclination without external ventilation		35°
Supply voltage
Type of supply voltage		18 V DC
UPS connectable (serial)		No
Input current
Current consumption (rated value)		0.3 A
Power
Active power input, typ.		8 W
Processor
Processor type		X86, 33 MHz
Drives
Diskette drive		No
CD-ROM		No
Hard disk		No
Memory
Type of memory		Flash / RAM
Memory available for user data		1 024 kbyte
Battery
Backup battery
● Backup battery (optional)		Yes; optional 3.6 V
● Backup time, min.		4 y
Type of output
Info LED		Yes
Power LED		No
Time of day
Clock
● Type		Hardware clock, battery backup, synchronizable
● retentive		Yes
● synchronizable		Yes
Interfaces
Interfaces/bus type		1 x TTY, 2 x RS232, 1 x RS422, 1 x RS485 (max. 12 Mbit/s)
Number of RS 485 interfaces		1
● Transmission rate, max.		12 Mbit/s
USB port		No
PC card slot		1 x PC card slot
CF card slot		No
Special interfaces		No
Industrial Ethernet
● Industrial Ethernet interface		No
Degree and class of protection
IP (at the front)		IP65
IP (rear)		IP20
Standards, approvals, certificates
Certifications		PRS, FM Class I Div. 2, UL, EX Zone 22
Ambient conditions
Ambient temperature during storage/transportation
● min.		-20 °C
● max.		60 °C
Relative humidity
● Operation, max.		95 %
Operating systems
pre-installed operating system		Rmos
Configuration
Configuration software
● Configuration tool		ProTool Version 3.1 or higher (to be ordered separately)
Dimensions
Width of the housing front		296 mm
Height of housing front		192 mm
Overall depth		59 mm

Bijzonderheden:

Het HMI paneel is gebruikt en getest.

Er kan nog een programma in zitten, dat nog overschreven moet worden.

Voor meer informatie over dit paneel klik op de pdf link

files/siemens Op27 - Op37_s.pdf

Er liggen veel meer materialen in ons magazijn die niet allemaal op de web-site staan.

Voor vragen kunt u altijd vrijblijvend contact met ons opnemen.
